DJI Action Camera Handheld Gimbal RS 5 Standard Black EU (CP.RN.00000496.03)

Product detailed description

Peripheral & Ports:

• Accessory Port: Ronin Series Accessories (RSA)/NATO Ports
• Mounting Options: 1/4"-20 Mounting Hole, Cold Shoe
• Camera Control Port: USB-C
• Multifunctional Port: USB-C

Battery:

• Model: BHX715-2150-15.48
• Type: LiPo 4S
• Capacity: 2150 mAh
• Energy: 33.29 Wh
• Voltage: 11.2 V to 17.8 V
• USB Input: 5 V/3 A, 9 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/3 A
• Max Standby Time: Approx. 14 hours
• Charging Time: Approx. 1 hour
• Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

Connections:

• Bluetooth: 5.0
• USB-C Charging Port

Ronin App Requirements:

• iOS 14.0 or above
• Android 9.0 or above

Languages Supported by Touchscreen:

English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance:

• Tested Payload: 3.0 kg (6.6 lbs)
• Maximum Controlled Rotation Speed:

  • Pan: 360°/s
  • Tilt: 360°/s
  • Roll: 360°/s
• Mechanical Range:

  • Pan Axis: 360° continuous rotation
  • Roll Axis: -95° to +240°
  • Tilt Axis: -112° to +214°
• Axis Lock: Auto
• Vertical Shooting: Supported

Mechanical & Electrical Properties:

• Operating Frequency: 2.4000-2.4835 GHz
• Bluetooth Transmitter Power: < 8 dBm
• Operating Temperature: -20° to 45° C (-4° to 113° F)

Weight:

• Gimbal: Approx. 1193 g (2.63 lbs) (including the Upper and Lower Quick-Release Plates and screws)
• Grip: Approx. 274 g (0.6 lbs)
• Quick-Open Tripod: Approx. 149 g (0.3 lbs)
• Upper and Lower Quick-Release Plates: Approx. 96 g (0.21 lbs) (including screws)

Dimensions:

• Folded: 247.4×115.7×258.7 mm (L×W×H, excluding camera, grip, and the Quick-Open Tripod)
• Unfolded: 223.2×192.2×418.8 mm (L×W×H, including grip, excluding camera and the Quick-Open Tripod)

Accessories:

• DJI RS Enhanced Intelligent Tracking Module:

  • Weight: Approx. 19 g (0.04 lbs)
  • Dimensions: 36.3×17.5×38.2 mm (L×W×H)
  • Tracking Distance: 0.5-10 m
  • Operating Environment: Illuminance > 20 lux
  • Trigger Methods: Gimbal trigger, gesture, gimbal touchscreen
  • Gesture Functions: Start/stop of tracking, start/stop of recording, framing adjustment
  • Power Consumption: Approx. 1 W
  • Operating Temperature: -10° to 45° C (14° to 113° F)
  • Mounting Method: Magnetic attachment
• Electronic Briefcase Handle:

  • Weight: Approx. 230 g (0.51 lbs)
  • Dimensions: 60×197.5×79.5 mm (L×W×H)
  • Standby Power Consumption: Approx. 0.2 W
  • Operating Temperature: -20° to 45° C (-4° to 113° F)

Included Accessories:

• Gimbal × 1
• Quick-Open Tripod × 1
• Lens-Fastening Support × 1
• Screw Kit × 1
• RS 5 Upper Quick-Release Plate × 1
• RS 5 Lower Quick-Release Plate × 1
• BG33 Battery Grip × 1
• Multi-Camera Control Cable (USB-C, 30 cm) × 1
• DJI Logo Sticker × 1
