SONOFF MINI-DIM WiFi Matter smart switch

Product detailed description

The Sonoff MINI-DIM WiFi is an extremely compact smart dimmer that turns an ordinary switch into an advanced smart home system. It features on/off switching, 0-100% continuous dimming, scenes, scheduling, remote and voice control, energy monitoring, and full integration with the Matter ecosystem via WiFi. It fits most installations, supports multiple lighting types, and fits in a standard recessed box. It's a quick way to add "smart" features to an existing installation - without cutting into walls or replacing fixtures.

Matter and efficient WiFi - one device, all platforms
With support for the Matter standard, the MINI-DIM works seamlessly with Apple Home, Google Home, Amazon Alexa, SmartThings and Home Assistant. You don't have to choose one system or worry about compatibility - the module works wherever you are. At the heart of the device is the energy-efficient ESP32-C3 chip, which provides fast operation, stable 2.4GHz WiFi connectivity and OTA updates. The MINI-DIM can acquire new features and enhancements with subsequent software releases, ensuring it will remain current for years to come.

Smooth, flicker-free dimming - light exactly as you want it
Back-edge dimming technology provides exceptionally smooth brightness control without flickering, buzzing or voltage fluctuations. The light adapts naturally to the situation - strong for work, soft for relaxation, atmospheric in the evening. Comfort for the eyes and a more pleasant atmosphere in every room. Built-in power metering allows you to control how much electricity the lighting consumes. This makes it easy to optimize the operation of the luminaires, eliminate unnecessary losses and reduce bills.

Wide compatibility with fixtures - install and it works
There is no need to replace lamps or adapt the installation to a specific type of lighting. MINI-DIM works seamlessly with dimmable LED bulbs up to 200 VA, conventional incandescent and halogen bulbs up to 400 W and dimmable electronic transformers up to 200 W. This means complete flexibility of use - from subtle decorative lighting to powerful main lighting in the living room or kitchen - without compromise or additional cost.

Intelligent control - app, voice, calibration and LAN
From the eWeLink app, you can remotely turn lights on and off, adjust brightness, set timers, scenes and automation, and control energy consumption. Voice assistant support allows you to control your lights with a command - without having to go to the switch. Built-in auto calibration automatically adjusts the dimming range to the connected fixture, eliminating flicker and dead zones of brightness. Plus, control works locally on the LAN, so the fixture responds instantly even without Internet access - faster, more stable and whenever you need it.

Robust construction and reliable electronics
The plastic housing made of fire-resistant PC V-0 in combination with high-quality electronic components ensures safe and stable operation. Built-in NTC temperature sensor, overheat protection, surge protection and shock protection effectively protect the installation and connected lighting. CE and RoHS certificates confirm compliance with European safety standards.

Easy installation, fast pairing, immediate effect
Connect the cables, pair the devices in the app or with Code Matter, and you're done. MINI-DIM works with conventional wall switches and completely wirelessly. With dimensions of only 45 × 39.4 × 16.8 mm, the MINI-DIM easily fits behind a traditional wall switch. Within minutes, you can transform your traditional lighting into an intelligent system that will improve your everyday comfort.

Specifications:

Communication Standard.
Wireless: WiFi 2.4 GHz IEEE 802.11 b/g/n
Control system (MCU): ESP32-C3
Supply voltage: 220-240 V AC
Frequency: 50 Hz
Maximum resistive load: 400 W
Maximum LED load: 200 VA
Supported lighting types: dimmable LED, traditional incandescent, halogen bulbs, electronic transformers
Dimming range: 0-100%
Brightness calibration: automatic
Energy consumption monitoring: yes
Local control via LAN: Yes
Voice control: yes
Support for scenes and plans: yes
OTA update: Yes
Neutral conductor required:Yes
Housing material: PC plastic, non-flammable
Coloured material: White
Dimensions: 45 × 39.4 × 16.8 mm
Weight: 24,5 g
Recommended conductor thickness: 18-16 AWG, copper
Installation place: indoor
Operating temperature: -10 °C to 40 °C
Operating humidity: 5-95% RH, non-condensing
Protection: overheat protection, overvoltage protection, NTC temperature protection

Contents of the package:

MINI-DIM Intelligent dimmer
User manual
