BKE JS-150-138/DIN2_CH_ODP 13.8 V, 150 W, 10 A, switching, PFC

Product detailed description

Product Description: BKE JS-150-138/DIN2_CH_ODP 13,8 V, 150 W, 10 A, switched with battery disconnector to prevent deep discharge and damage. The power supply has short circuit and overload protection at the output, overvoltage and undervoltage protection at the output and thermal protection. The charger is equipped with active power factor compensation (PFC). The power supply is suitable for powering information and telecommunication equipment with DC voltage backup. The power supply has an efficiency of more than 80% and a great advantage is the 5-year warranty period. The power supply can be operated without a battery connected. Main features: Switching power supply Output voltage: 13.8 V DC Backup current: max. 10 A Output power: 138 W DIN35 rail mounting Input voltage: 180 - 260 V AC, 47-63 Hz, active PFC Mains failure overlap time: 20 ms/230 V AC Efficiency: 87 % Protections: output short circuit protection (with external battery protection), overload protection, output overvoltage and undervoltage protection, thermal protection Integrated disconnector (LVD) to protect the battery from deep discharge Charging temperature compensation Disconnection voltage: 10.5 V Indication LED Fanless, airflow cooling Connection via screw terminals up to 2.5 mm2, double output terminals Other parameters: Max. input current: 1 A/230 V AC (2 A/100 V AC) Input protected by 4 A/250 V fuse Power factor: 0.99 Protection: IP20 (IP00 terminals) Box material: Al sheet metal Electrical strength input-output: 3 kV AC/1 min Electrical strength input-to-ground: 1.5 kV AC/1 min Insulation resistance: >50 MOhm SELV type output circuits Automatic battery connection when output voltage is restored U characteristic with current limitation The power supply is designed as protection class I, overvoltage category 3 in installation according to EN 61010-1 Standards: Safety: EN 60950-1 ed.2 EMC: EN 61000-6-1 ed.2, EN 61000-6-3 ed.2 Working conditions: Temperature: -20° to +50°C Humidity: relative 10 - 80% (non-condensing) Dimensions: 55 x 125 x 134 mm (without clip) Weight: 0.8 kg
