BKE JS-300-545/DIN2_CH 54.5 V, 300 W, 5 A, switched

Product detailed description

Switching power supply - IU charger with high reliability and active PFC. Designed for powering back-up devices and systems. Equipped with a decoupling diode at the output and a potential-free contact for remote reporting of the power supply operation. Possibility to connect a backup battery in parallel to the output of the power supply. Mounting on 35 mm DIN rail. Green LED indication of operation. Product parameters: Output Efficiency approx. 87% 10 ms/230 V AC mains failure overlap time Thermal protection Output short circuit protection Double output terminals up to 2.5 mm2 Other data Protection IP 20 Dimensions 70 x 155 x 175 mm Operating temperature -20 to +50 °C Storage temperature -25 to +70 °C Rel. operating humidity 10-90% RH Rel. storage humidity 10-95% RH Weight 1.4 kg Separation diode on output (available on request) Standards Safety EN 60950-1 ed.2 EMC EN 61000-6-1 ed.2, EN 61000-6-3 ed.2 Electrical strength input/output 3kV AC/1 Min., input/ground 1.5kV AC/1 Min. SELV type output circuits
