Power supply BKE SS-150-480/DIN2 20-32V

Product detailed description

Switching DC/DC converter, galvanically isolated with stabilized output voltage designed to power equipment for industrial and control applications. DIN rail mountable, operation indication by LED. Can be supplied with 60 V input voltage. At temperatures between 40 °C and 50 °C, the output power must be reduced linearly by 2%/°C. Input Power input 170-190 W (depending on type) Over-polarity protection Input screw terminals up to 2.5 mm Output Efficiency 80 to 90% Output short-circuit protection, power protection Dual output terminals up to 2.5 mm Other data Protection IP20 Dimensions 134x125x55 mm Operating temperature -20 °C to +50 °C Storage temperature -20 °C to +70 °C Operating relative humidity 10-80% Relative humidity storage 10-90 % Weight 0.80 kg Standards Safety EN 60950-1 ed.2 EMC EN 61000-6-1 ed.2 EN 61000-6-3 ed.2 Impact resistance 500V AC input-output/1min Impact resistance 500V AC input-to-ground/1min
