Power supply/charger for DIN rail BKE JS-300-545/DIN2_CH - SOLD 54,5 V, 300 W, 5 A, switched
Code: ABCT_A500004645Product detailed description
It is a BKE power supply/charger for DIN rail. The product is unused, only unpacked and returned by the client. This is a fully functional product, sold with full 24 months warranty. All clean, undamaged. WITHOUT original packaging.
Switching power supply - IU charger with high reliability and active PFC. Designed for powering back-up devices and systems. Equipped with a decoupling diode at the output and a potential-free contact for remote reporting of the power supply operation. Possibility to connect a backup battery in parallel to the output of the power supply. Mounting on 35 mm DIN rail. Green LED indication of operation.
Product parameters:
Retrieved from
Efficiency > 80%
Mains failure overlap time 10 ms/230 V AC
Thermal protection
Output short circuit protection
Double output terminals up to 2.5 mm2
Other data
Protection IP 20
Dimensions 70 x 155 x 175 mm
operating temperature -20 to +50 °C
storage temperature -20 - +70 °C
Rel. working humidity 10-90% RH
Rel. storage humidity 10-95% RH
Weight 1,4 kg
Separation diode at the output (available on request)
Standards
safety EN 60950-1 ed.2
EMC EN 61000-6-1 ed.2, EN 61000-6-3 ed.2
Electrical strength Input/output 3kV AC/1 Min., input/ground 1.5kV AC/1 Min.
SELV type output circuits
Additional parameters
| Category: | ABC Tech |
|---|---|
| Weight: | 1.5 kg |
