Power supply for DIN rail BKE JS-75-240/DIN2 24 V, 75 W, 3 A, switching

Product detailed description

Industrial power supply for DIN rail BKE JS-75-240/DIN2 24 V, 75 W, 3 A, switched with protection against short circuit at output, overload and overvoltage. The power supply is suitable for powering information and telecommunication equipment. The power supply has an efficiency of more than 85%. Main features: Switching power supply Output voltage: 24 V DC, ±3% Output current: max. 3 A Output power: 75 W (60 W at 115 V AC input voltage) DIN35 rail mounting Input voltage: 100 - 260 V AC, 47-64 Hz Efficiency: 85 - 91 % Protection: short circuit, overload, overvoltage Indication LED Fanless, airflow cooling Connection via screw terminals up to 2.5 mm2 Other parameters: Max. input current: 1 A/ 230 V AC Peak inrush current: 66 A/230 V AC Input protected by a 2 A/250 V fuse No-load power: 0.7 W Protection: IP20 (IP00 terminals) Box material: Al sheet metal Electrical strength input-output: 3 kV AC/1 min Electrical strength input-to-ground: 1.5 kV AC/1 min Insulation resistance: >50 MOhm SELV type output circuits The power supply is designed as protection class I, overvoltage category in installation 3 according to EN 61010-1 Standards: Safety: EN 60950-1 ed.2 EMC: EN 61000-6-1 ed.2, EN 61000-6-3 ed.2 Working conditions: Temperature: 0° to +50°C Humidity: relative 10 to 80% (non-condensing) Dimensions: 90 x 88 x 58 mm Weight: 0.3 kg
