Solarix patch panel 19" ISDN 25 x RJ45 black 1U SX25-ISDN-BK

Product detailed description

Solarix ISDN patch panel SX25-ISDN-BK is a high quality telephone panel designed for the part of the structured cabling, which is used to connect user workstations to the telephone exchange. The panel is equipped with 25 RJ45 ports and termination modules with dual 110/Krone terminals. The panel includes a tie bar, which allows for a clear arrangement and firm attachment of the telephone cable directly to the body of the patch panel. The advantages of the Solarix ISDN panels are their high reliability, durability and above all their easy installation. The panels meet all requirements defined for category 3. The colour of Solarix ISDN patch panels is black. The size in the data rack is 1U. Technical parameters: CAT3 category Supported protocols: 10BaseT Number of ports: 25 Tie bar: yes Min. port life: 750 connections/disconnections Contact Coverage: 15 µ gold and 100 µ nickel Terminal block: dual 110/Krone 4p4c Min. terminal life: 200 notches Wire size and type: AWG 26 - 22 Material of non-metallic parts: FR plastic according to UL94-0 Color: Black Size: 1U Height: 44 mm Width: 484 mm Depth: 129 mm Storage temperature: -40 to 70°C Operating temperature: -10 to 60°C Max. operating humidity: 93% Packing: 1 piece, carton
