Tinycontrol SCD40 CO2 concentration, humidity and temperature sensor, for LAN driver v3/v4, I2C, black

Product detailed description

Tinycontrol SCD40 Sensor, CO2, humidity and temperature measurement, photoacoustic measurement, for LAN driver v3/v4, I2C, 2,4-5,5VDC, black Sensor for CO2 concentration using newly developed photo-acoustic technology. Integrated cable with RJ-12 connector facilitates direct connection to the LAN Controller. Compatibility - LK4 - LK4mini - LK3.9 - LAN Controller v3.5 (from firmware 1.57) BASIC SPECIFICATIONS Sensor type: SCD40 - CO2, temperature and humidity Measuring principle: photoacoustic sensing Interface: I2C, RJ-12 Supply voltage: DC 2.4-5.5 V (typically 3.3/5 V) Peak current draw: 175 mA Dimensions: 59 × 27 mm Specifications: Supply voltage: 2.4-5.5 V DC (typically 3.3 V or 5 V) 175 mA peak supply current Connector: RJ12 Cable length: 28 cm Dimensions: 27 x 59 mm Sensing power: CO2 - Output range: 0-40,000 ppm - Measuring range: 400-2,000 ppm - Measurement accuracy: ±(50 ppm + 5%) (in the range of 400-2,000 ppm) - Measurement repeatability: ±10 ppm - Response time: 60 s Moisture sensing performance - Measuring range: 0-100 % relative humidity - Measurement accuracy: ±6 % RH (15 °C - 35 °C, 20 % RH - 65 % RH) ±9 % RH (-10 °C - 60 °C, 0 % RH - 100 % RH) - Measurement repeatability: ±0,4 % RH - Response time: 90 s Temperature sensing performance - Measurement range: -10 to +60 °C - Measurement accuracy: ±0.8 °C (15 °C - 35 °C) ±1.5 °C (-10 °C - 60 °C) Measurement repeatability: ±0.1 °C Response time: 120 s
