3M Fibrlok II 2529 Optical fibre mechanical gel connector for SM/MM fibres with protection

Product detailed description

Fibrlok™ II 2529 universal optical mechanical coupler is developed for mechanical coupling of optical fibers with primary protection diameter from 250 lm to 900 lm. The coupler is designed for splicing single-mode and multi-mode optical fibers with a nominal fiber diameter of 125 lm. Parameters and specifications: - Fiber diameter: 125 lm - Coating diameter: 250 lm or 900 lm tight jacket - Mean insertion loss: < 0.1 dB - Reflection attenuation: < -40 dB - Operating temperature: -40 °C to 80 °C - Dimensions: 3.8 x 6.4 x 38.1 mm - Indoor and outdoor use - Single and multifilament - For construction and maintenance - Full replacement for optical welds - No epoxy or electricity required Characteristics - Integrated coupling - Minimum tooling requirements - Three-point attachment of spliced fibers Benefits - Simple operation when joining the fibre - Increased productivity - Easy on-site installation - High performance - Lower costs, minimal training - Permanent and temporary fast fiber optic splicing
