Cabinet for distributors 485 mm - overhead

Product detailed description

Overhead cabinets for heating distributors are commonly used in residential and commercial buildings to house and protect manifold systems for underfloor heating or radiator circuits. These cabinets are typically mounted on walls in mechanical rooms, utility areas or behind access panels. Installers must ensure that the cabinet dimensions match the distributor size and that the installation allows for easy access to valves and connections. The AVANSA 1210HPX model is specifically designed for systems with 5–6 circuits and offers a compact depth of 120 mm, making it suitable for tight spaces.

Proper installation requires careful planning to align the cabinet with the floor level and to allow for vertical and horizontal adjustments. The nickel-plated lock ensures secure closure and prevents tampering. The white enamel finish is resistant to corrosion and wear, making it suitable for long-term use in humid or high-traffic environments. The cabinet is mounted using either a snap-fit or screw-fixed method, depending on the wall type and load requirements.

Technical parameters

Dimensions	485 x 580 x 120 mm (width x height x depth)
Finish	White enamel
Code	1210HPX
Brand	AVANSA

The internal dimensions of the AVANSA 1210HPX are 485 mm in width, 580 mm in height and 120 mm in depth. These measurements are critical for selecting the correct cabinet size based on the number of circuits in the distributor. A 485 mm width is suitable for distributors with 5–6 circuits, as listed in the manufacturer's sizing table. The fixed depth of 120 mm ensures compatibility with standard manifold systems and allows for sufficient clearance around the piping and valves.

Installation and connection

The AVANSA 1210HPX is installed by either snapping it into place or securing it with screws to the wall. The installation method depends on the wall material and the load-bearing requirements. The cabinet must be levelled to ensure proper alignment with the floor and to prevent uneven stress on the distributor. The nickel-plated lock should be tested after installation to confirm secure closure. Common installation errors include incorrect wall fixing, misalignment with the distributor, or failure to allow sufficient space for pipe routing and valve access. The cabinet is not designed for use with a built-in pump, so additional pump enclosures must be considered separately.

Compatibility and accessories

The AVANSA 1210HPX is compatible with standard heating distributors that fit within the 485 mm width and 580 mm height. It is intended for use with distributors that have 5–6 circuits, as specified in the manufacturer's product table. No additional accessories are included with the cabinet, but installers may need to order separate mounting hardware or sealing materials depending on the installation environment. The model is not available with an integrated pump, so pump enclosures or separate pump housings must be selected independently.

Technical background for designers

The AVANSA 1210HPX is constructed from durable, corrosion-resistant materials and finished in white enamel to provide a clean, professional appearance. The cabinet acts as a protective enclosure for the distributor, shielding it from physical damage and environmental factors. The fixed depth of 120 mm is designed to accommodate standard manifold systems without requiring excessive space. The nickel-plated lock ensures secure closure and prevents unauthorised access. The design allows for vertical and horizontal adjustments to align with the floor and wall surfaces, which is important for maintaining system integrity and ease of maintenance. The choice of cabinet size directly affects the system's accessibility and long-term performance.

Service and operation

The AVANSA 1210HPX requires minimal maintenance beyond regular visual inspections for signs of damage or wear. The lock mechanism should be checked periodically to ensure it operates smoothly and securely. No specific service intervals are provided in the technical data. The cabinet should be kept clean and free from debris to prevent obstruction of the distributor components. If the cabinet is installed in a high-moisture environment, it is recommended to inspect for signs of condensation or corrosion on a routine basis.

Frequently asked questions

Can the AVANSA 1210HPX be used with a distributor that has 4 circuits?
No, the model is specifically designed for distributors with 5–6 circuits. A smaller cabinet such as the 1200HPX would be required for 2–4 circuits.

Is the AVANSA 1210HPX suitable for use with a built-in pump?
No, the model is not designed for use with a built-in pump. Pump enclosures or separate pump housings must be selected independently.

Can the cabinet be adjusted to different floor levels during installation?
Yes, the cabinet allows for vertical and horizontal adjustments to align with the floor and wall surfaces during installation.

What type of lock is used on the AVANSA 1210HPX?
The cabinet features a nickel-plated lock that provides secure closure and prevents unauthorised access.
