Nut for solar pipe - set DN12

Product detailed description

The AVANSA 602SET SOLARU DN12 is commonly used in solar thermal installations to terminate stainless steel piping systems. It is typically found in residential and commercial solar heating systems where precise and durable pipe termination is required. Installers working with solar collectors and heat exchangers will encounter this set when connecting piping to collector manifolds or system junctions. The set ensures a reliable seal and mechanical support, reducing the risk of leaks and misalignment in high-temperature environments.

Correct installation of this termination set is essential to maintain system integrity and thermal efficiency. The set is designed to be used with standard DN12 stainless steel tubing and is compatible with typical solar system configurations. It is often used in conjunction with deformation screws to shape the pipe for a secure fit. The brass components provide corrosion resistance and mechanical stability, while the high-temperature gasket ensures a long-lasting seal.

Technical parameters

Nominal diameter	DN 12
Weight	0.1 kg
Code	602SET SOLARU DN12
Brand	AVANSA

The nominal diameter of DN12 corresponds to a 1/2 inch thread size, ensuring compatibility with standard solar piping systems. This parameter is critical for correct sizing and selection, as it defines the internal flow capacity and connection compatibility. The set is designed for use with stainless steel tubing of the same nominal size.Installation and connection To install the AVANSA 602SET SOLARU DN12, first ensure that the stainless steel pipe is properly shaped using a deformation screw. The brass nut is then threaded onto the pipe, with the support ring and gasket positioned between the nut and the pipe end. The nut should be tightened until the gasket forms a secure seal. It is important to check that the pipe is not bent or misaligned before tightening, as this can cause uneven pressure on the gasket and lead to leaks. Common installation mistakes include over-tightening the nut, which can damage the gasket, and using incorrect thread sizes, which can prevent a secure fit.Compatibility and accessories This set is specifically designed for DN12 stainless steel solar piping and is compatible with standard solar system components. It is recommended to use a deformation screw DN12 for shaping the pipe before installation. Additional components such as stainless steel pipe DN12-DN25 and solar double pipe systems may also be required. Related products include deformation screws DN12, stainless steel corrugated pipe DN16, and solar double pipe systems. Ensure that all components are from the same system to maintain compatibility and system integrity.Technical background for designers This termination set functions by providing a mechanical and sealing interface between the solar pipe and the system manifold. The brass nut offers high strength and resistance to thermal expansion, while the high-temperature gasket ensures a durable seal even under fluctuating temperatures. The support ring helps maintain alignment and prevents stress on the pipe joint. The integration of this set into the system depends on the overall design of the solar piping network, including the number of terminations and the layout of the collectors. The material properties of brass and the gasket are selected to withstand the thermal cycling typical of solar systems, ensuring long-term performance and reliability.Service and operation During operation, it is important to periodically inspect the termination set for signs of wear, such as gasket degradation or mechanical loosening. If the system is exposed to extreme temperature fluctuations, additional checks may be necessary to ensure the integrity of the seal. No specific service intervals are provided in the brief, but any visible damage or leakage should be addressed immediately to prevent system failure. The brass components are generally maintenance-free, but the gasket may need to be replaced if it shows signs of deterioration.Frequently asked questions

Can the AVANSA 602SET SOLARU DN12 be used with stainless steel corrugated pipe?
Yes, the set is designed for use with DN12 stainless steel pipe and can be used with corrugated pipe provided the deformation screw is used to shape the pipe correctly.

Is a deformation screw required for installation?
Yes, a deformation screw DN12 is recommended to shape the pipe before installation to ensure a secure fit and proper sealing.

Can this set be used in high-temperature solar systems?
Yes, the high-temperature gasket included in the set is suitable for use in solar systems operating at elevated temperatures.

Can multiple sets be used in a single solar system?
Yes, multiple sets can be used depending on the number of pipe terminations required in the system. It is recommended to order two deformation screws per set to account for potential loss during installation.
