Main features:
Easily accessible terminals:
Installation is easier than ever because the terminals are now more accessible to the installer.
VE.Direct:
The VE.Direct port can be connected to:
- Computer (VE.Direct to USB interface cable required)
- Smartphones, tablets, MacBooks and other Apple and Android devices (VE.Direct Bluetooth Smart dongle required)
Fully configurable:
- Triggering low battery alarm and resetting levels
- Low battery shutdown and restart levels
- Dynamic shutdown: load-dependent shutdown level
- Output voltage 210 - 245 V
- Frequency 50 Hz or 60 Hz
- ECO mode on/off and ECO mode scan level
Tracking:
- Input and output voltages, % load and alarms
Proven reliability:
The full bridge and toroidal transformer topology has proven its reliability over many years. The inverters are short-circuit proof and protected against overheating, whether due to overload or high ambient temperature.
High starting power:
Needed to run loads such as inverters for LED bulbs, halogen bulbs, refrigerators or power tools.
ECO mode:
In ECO mode, the inverter switches to standby mode when the load drops below the preset value. In standby mode, the inverter switches on briefly every 2.5 seconds (adjustable). If the load exceeds the preset level, the inverter will remain on.
Remote on/off:
The remote switch can be connected to the two-pole connector or between the battery plus and the left contact of the two-pole connector.
LED diagnostics:
The status LEDs can be used to diagnose the device, see the user manual.
Victron Connect:
The VictronConnect application is used to monitor, control and configure the inverter. The app can be installed on your phone, tablet or computer. The app is available for Android, iOS, Windows and macOS. The app communicates either via Bluetooth or via a USB interface with the VE.Direct port.
Technical parameters:
- output voltage: 230 V AC +/- 3% 50 Hz or 60 Hz +/- 0.1%
- continuous power at 25 ºC: 1200 VA / 1000 W
- peak power: 2200 W
- max. efficiency: 91 %
- self-consumption at zero load: max 7 W
- self-consumption in ECO mode: max 1 W
- 230 V AC: Schuko (CEE 7/4)
- operating temperature range: -40 to +65ºC (fan-assisted cooling)
- humidity (non-condensing): max. 95 %
- protection class: IP21
- weight: 7,4 kg
- dimension: 117 x 232 x 327 mm
Victron Energy products are guaranteed for 5 years by the manufacturer.
