Mean Well DDR-240C-48 DC/DC voltage converter for DIN rail 48 V/DC 5 A 240 W 1 x

Product detailed description

MEANWELL DDR-240 series of DC/DC converters for DIN rail Single Output, input voltage ratio 2:1 power: 240 W Special features For DIN rail mounting. - Can be installed on TS-35/7.5 or 15 DIN rail - Width only 40 mm - Input voltage range 2:1 - 150% of maximum load - Adjustable voltage output - Cooling due to free air convection - Insulation voltage between input and output 4000V - Protection This text has been machine translated. Characteristics Can be installed on DIN rail TS-35/7.5 or 15 Width only 40 mm input voltage range 2:1 150% peak load capacity regulated output voltage cooling due to free air convection isolation voltage between input and output 4000V Protection: short circuit, overload, overvoltage, overheating, input reverse polarity, input under voltage protection Technical parameters Input Voltage See 33.6. Recital of the decision of the company S 67,2V/DC Output current (max) 5A Output current (max.) - rounded 5A Number of outputs 1x Dimensions (l x w x h) 40 x 113.5 x 125.2 mm Weight 760g H 125.2mm Length 40mm Width 113.5mm Connection clamp Output Type (Power Supplies) Adjustable Features DC/DC converter, stabilized , adjustable output voltage Manufacturer ID DDR-240C-48 Type DDR-240C-48 MTBF 484900h Rated input voltage 48 V/DC Efficiency 92% Input voltage (max) 67.2V/DC Input voltage (min.) 33.6V/DC Operating Temperature (max.) +70°C Operating temperature (min.) -40°C Output voltage (max.) 56V/DC Output voltage (min.) 48V/DC Output voltage (max.) 48V/DC Power 240W Output voltage 48V/DC Product Category DC/DC voltage converter for DIN rail
